Main Input Voltage: 230 V
Other Input Voltage: 220 V, 240 V
Main Output Voltage: 230 V
Other Output Voltage: 220 V, 240 V
Rated power in W: 6000 W
Rated power in VA: 6000 VA
Output connector type: Hard wire 3-wire (1P + N + E) 1
Number of rack unit: 4U
Battery type: Lead-acid battery
Battery voltage: 192 V
Number of battery filled slots: 0
Number of battery free slots: 0
Battery recharge time: 4 h
Battery life: 3…5 year(s)
Battery charger power: 235 W rated
Input
Input voltage limits: 110...300 V 60 % load 176...300 V full load
Number of input connectors: 1 hard wire 3-wire (1P + N + E)
Network frequency: 40...70 Hz auto sensing
Output
Maximum configurable power in VA: 6000 VA
Maximum configurable power in W: 6000 W
Output frequency: 50/60 Hz +/- 3 Hz sync to mains
Harmonic distortion: 1 %
UPS type: Double conversion online
Wave type: Sine wave
Efficiency: 94 % (full load)
Additional information
Configurable for 220 : 230 or 240 nominal output voltage
Bypass type: Internal bypass (automatic and manual)
Crest factor: 3 : 1
Warranty: 2 years repair or replace
