Main Input Voltage: 230 V
Other Input Voltage: 220 V, 240 V
Main Output Voltage: 230 V
Other Output Voltage: 220 V, 240 V
Rated power in W: 900 W
Rated power in VA: 1000 VA
Input Connection Type: IEC 60320 C14
output connection type: 3 IEC 60320 C13
Input
Input voltage limits: 110...285 V half load, 180...285 V full load
Network frequency: 40...70 Hz auto sensing
Output
Maximum configurable power in VA: 1000 VA
Maximum configurable power in W: 900 W
Output frequency: 50/60 Hz +/- 3 Hz sync to mains
Harmonic distortion: 3 %
UPS type: Double conversion online
Wave type: Sine wave
Efficiency: 88 % (full load)
Configurable for 220 : 230 or 240 nominal output voltage
Bypass type: Internal bypass (automatic and manual)
Crest factor: 3 : 1
Environmental
ambient air temperature for operation: 0…40 °C
Relative humidity: 0…95 % non-condensing
Operating altitude: 0...3000 m
Ambient air temperature for storage: -20…50 °C
Storage Relative Humidity: 0…95 % non-condensing
Storage altitude: 0…15000 m
Acoustic level: 50 dBA
heat dissipation: 380 Btu/h
IP degree of protection: IP20
Warranty: 2 years repair or replace
