Output power capacity: 1.98 KWatts / 2.2 k
VAMax Configurable Power (Watts): 1.98 KWatts / 2.2 kVA
Nominal Output Voltage: 230V
Output Voltage Note Configurable for 220 : 230 or 240 nominal output voltageOutput Voltage
Distortion Less than 2%
Output Frequency (sync to mains) 50/60Hz +/- 3 Hz
Other Output Voltages 220, 240
Load Crest Factor: 3 : 1
Topology: Double Conversion Online
Waveform type Sine waveOutput Connections:(8) IEC 320 C13 (Battery Backup);(2) IEC 320 C19 (Battery Backup);(2) IEC Jumpers (Battery Backup)
Bypass: Internal Bypass (Automatic and Manual)
Input
Nominal Input Voltage: 230V
Input frequency: 40 - 70 Hz (auto sensing)
Input Connections: IEC-320 C20, Schuko CEE 7 / EU1-16P, British BS1363A
Cord Length: 2.44meters
Input voltage range for main operations: 160 - 275V
Input voltage adjustable range for mains operation: 100 - 275 (half load)
VNumber of Power Cords: 1
Other Input Voltages 220, 240
Batteries & Runtime
Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules: 1Typical recharge time: 3hour(s)
Replacement Battery:APCRBC141
Expected Battery Life (years): 3 - 5R
BC Quantity: 1
Extendable Run Time: 1
Battery Volt-Amp-Hour Capacity: 367
Extended Run OptionsAPC-Smart-UPS-SRT-2200VA-230V
Runtime: View Runtime Graph View Runtime Chart
EfficiencyView: Efficiency Graph
Communications & Management
Interface Port(s): RJ-45 Serial , Smart-Slot , USB
Control panel: Multi-function LCD status and control console
Audible Alarm: Audible and visible alarms prioritized by severity
Emergency Power Off (EPO): Yes
Available SmartSlot™ Interface Quantity: 1
Physical
Maximum Height: 432mm , 43.2cm
Maximum Width: 85mm , 8.5cm
Maximum Depth: 584mm , 58.4cm
Net Weight: 25.0kg
Shipping weight:30.84kg
Shipping Height: 246mm , 24.6cm
Shipping Width: 599mm , 59.9cm
Shipping Depth: 810mm , 81.0cm
Color: Black
Units per Pallet: 12.0
Conformance
Approvals: CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, ENERGY STAR (EU), RCM, VDE
Standard warranty: 3 years repair or replace (excluding battery) and 2 years for battery
